10.9 Steel Hex Head Screws
Description
Technical Parameters
Product description:
To ensure optimal performance in demanding situations such as automotive suspension systems, valves, pumps, and motors, it is recommended to utilize 10.9 Steel Hex Head Screws. These screws have been specifically designed to handle high levels of stress, providing the necessary strength and durability for critical applications. By opting for these screws, you can rely on their ability to withstand intense pressures and maintain structural integrity. Perfectly suited for heavy-duty tasks, they offer a reliable solution to meet the demands of challenging environments. Whether you are working with valves, pumps, motors, or automotive suspension systems, these 10.9 Steel Hex Head Screws are the ideal choice to ensure reliable and long-lasting performance.
Medium-strength steel screws can't hold a candle to their 25% stronger counterparts. These stronger screws are built to withstand even the toughest of conditions with ease.
Our dimensions are in compliance with ISO (previously known as DIN) or DIN standards.
The length is measured from the head down.
To ensure long-lasting durability and protection against corrosion, opt for black ultra-corrosion-resistant coated steel screws. These screws have been specially designed to withstand harsh chemicals and can even endure up to 1,000 hours of exposure to salt spray. However, it is important to maintain their corrosion resistance by incorporating black ultra-corrosion-resistant coated nuts and washers into your assembly. By using these compatible accessories, you can enhance the performance and longevity of your connections, even in challenging environments.
When matching mating components, it is essential to consider their thread spacing. The industry standard is coarse threads, which are recommended if you are unsure of the pitch. On the other hand, fine and extra fine threads are designed to prevent loosening caused by vibration. The closer arrangement of these threads provides better resistance, with the thinner threads offering the highest level of resistance. Remember to select the appropriate thread spacing for optimal performance and durability.
Mechanical and physical properties:
Property Class | Class 10.9 |
Tensile Strength | 1040Mpa min. |
Stress at 0.2% permanent strain | 940Mpa min. |
Percentage elongation after fracture for machined test pieces, A, % | 9 min. |
Percentage reduction of area after fracture for machined test pieces, Z, % | 48 min. |
Rockwell hardness, HRC | 32-39 |
Product Drawing:
Hex bolt partially threaded GradeA and B | ||||||||||||||
GB/T 5782-2016 & ISO 4014-2011 | ||||||||||||||
| ||||||||||||||
d | P(mm) | b (mm) | ds (mm) | k (mm) | s (mm) | |||||||||
min | max | A | B | min | max | |||||||||
L≤125 | 125＜L≤200 | L＞200 | A | B | min | max | min | max | A | B | ||||
M1.6 | 0.35 | 9 | 15 | 28 | 1.46 | 1.35 | 1.6 | 0.975 | 1.225 | 0.9 | 1.3 | 3.02 | 2.9 | 3.2 |
M2 | 0.4 | 10 | 16 | 29 | 1.86 | 1.75 | 2 | 1.275 | 1.525 | 1.2 | 1.6 | 3.82 | 3.7 | 4 |
M2.5 | 0.45 | 11 | 17 | 30 | 2.36 | 2.25 | 2.5 | 1.575 | 1.825 | 1.5 | 1.9 | 4.82 | 4.7 | 5 |
M3 | 0.5 | 12 | 18 | 31 | 2.86 | 2.75 | 3 | 1.875 | 2.125 | 1.8 | 2.2 | 5.32 | 5.2 | 5.5 |
M3.5 | 0.6 | 13 | 19 | 32 | 3.32 | 3.2 | 3.5 | 2.275 | 2.525 | 2.2 | 2.6 | 5.82 | 5.7 | 6 |
M4 | 0.7 | 14 | 20 | 33 | 3.82 | 3.7 | 4 | 2.675 | 2.925 | 2.6 | 3 | 6.78 | 6.64 | 7 |
M5 | 0.8 | 16 | 22 | 35 | 4.82 | 4.7 | 5 | 3.35 | 3.65 | 3.26 | 3.74 | 7.78 | 7.64 | 8 |
M6 | 1 | 18 | 24 | 37 | 5.82 | 5.7 | 6 | 3.85 | 4.15 | 3.76 | 4.24 | 9.78 | 9.64 | 10 |
M8 | 1.25 | 22 | 28 | 41 | 7.78 | 7.64 | 8 | 5.15 | 5.45 | 5.06 | 5.54 | 12.73 | 12.57 | 13 |
M10 | 1.5 | 26 | 32 | 45 | 9.78 | 9.64 | 10 | 6.22 | 6.58 | 6.11 | 6.69 | 15.73 | 15.57 | 16 |
M12 | 1.75 | 30 | 36 | 49 | 11.73 | 11.57 | 12 | 7.32 | 7.68 | 7.21 | 7.79 | 17.73 | 17.57 | 18 |
M14 | 2 | 34 | 40 | 53 | 13.73 | 13.57 | 14 | 8.62 | 8.98 | 8.51 | 9.09 | 20.67 | 20.16 | 21 |
M16 | 2 | 38 | 44 | 57 | 15.73 | 15.57 | 16 | 9.82 | 10.18 | 9.71 | 10.29 | 23.67 | 23.16 | 24 |
M18 | 2.5 | 42 | 48 | 61 | 17.73 | 17.57 | 18 | 11.285 | 11.715 | 11.15 | 11.85 | 26.67 | 26.16 | 27 |
M20 | 2.5 | 46 | 52 | 65 | 19.67 | 19.48 | 20 | 12.285 | 12.715 | 12.15 | 12.85 | 29.67 | 29.16 | 30 |
M22 | 2.5 | 50 | 56 | 69 | 21.67 | 21.48 | 22 | 13.785 | 14.215 | 13.65 | 14.35 | 33.38 | 33 | 34 |
M24 | 3 | 54 | 60 | 73 | 23.67 | 23.48 | 24 | 14.785 | 15.215 | 14.65 | 15.35 | 35.38 | 35 | 36 |
M27 | 3 | 60 | 66 | 79 | / | 26.48 | 27 | / | / | 16.65 | 17.35 | / | 40 | 41 |
M30 | 3.5 | 66 | 72 | 85 | / | 29.48 | 30 | / | / | 18.28 | 19.12 | / | 45 | 46 |
M33 | 3.5 | / | 78 | 91 | / | 32.38 | 33 | / | / | 20.58 | 21.42 | / | 49 | 50 |
M36 | 4 | / | 84 | 97 | / | 35.38 | 36 | / | / | 22.08 | 22.92 | / | 53.8 | 55 |
M39 | 4 | / | 90 | 103 | / | 38.38 | 39 | / | / | 24.58 | 25.42 | / | 58.8 | 60 |
M42 | 4.5 | / | 96 | 109 | / | 41.38 | 42 | / | / | 25.58 | 26.42 | / | 63.1 | 65 |
M45 | 4.5 | / | 102 | 115 | / | 44.38 | 45 | / | / | 27.58 | 28.42 | / | 68.1 | 70 |
M48 | 5 | / | 108 | 121 | / | 47.38 | 48 | / | / | 29.58 | 30.42 | / | 73.1 | 75 |
M52 | 5 | / | 116 | 129 | / | 51.26 | 52 | / | / | 32.5 | 33.5 | / | 78.1 | 80 |
M56 | 5.5 | / | / | 137 | / | 55.26 | 56 | / | / | 34.5 | 35.5 | / | 82.8 | 85 |
M60 | 5.5 | / | / | 145 | / | 59.26 | 60 | / | / | 37.5 | 38.5 | / | 87.8 | 90 |
M64 | 6 | / | / | 153 | / | 63.26 | 64 | / | / | 39.5 | 40.5 | / | 92.8 | 95 |
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory and OEM are available.
Q: How long is your delivery time?
A: Generally it is 2-5 days if the goods are in stock,or it is 15-30 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: 30% T/T in advance ,balance before shipment or L/C.
If you have another question, please feel free to contact us.
